DC 12V 10Amp Reversing Relay Module, Support Limit Switch, for Motor/Linear Actuator
US$10.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by www.heroldtaxi.ch
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
US$10.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by www.heroldtaxi.ch
Free 30-day returns Details
Product details
| Management number | 220308085 | Release Date | 2026/05/03 | List Price | US$10.00 | Model Number | 220308085 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Reversing relay module. Powers any reversing motor equipment, can be used for any application that requires the ability to reverse motion.
- Support Momentary-action(Self-resetting) switch and Alternate-action (Self-holding) switch. For Self-resetting switch, when the switch is pressed the motor operates, and when the switch is released the motor stops.
- Support external connect forward and reverse limit switch function. If you don't need the limit switch function, just short-circuit it.
- Compact plastic case and wires connect for easy mount.
- Forward and Reverse status indicating LED, forward status lighting red, reverse lighting green. When the control switch is not turned on, the module does not consume electric energy.
- Operating Voltage: 10 - 15V DC, Rated current 10 Amp.
| Model | DC 12V |
|---|---|
| Brand Name | OONO |
| Part Number | F-1081 Series |
| Coil Voltage | 10 Volts (DC) |
| Contact Type | 2no 2nc |
| Manufacturer | CZH-LABS |
| Mounting Type | Screw Mount |
| Connector Type | Cable |
| Current Rating | 10 Amps |
| Operation Mode | Manual |
| Contact Material | Copper |
| Included Components | Reversing relay module |
| Contact Current Rating | 10 Amps |
